Prices CF10-G56S4 HIMMEL Macedonia

BRAND	HIMMEL
Product	CF10-G56S4
Description	worm gear motor
Internal code	ONR3909015
Weight	8.8
Technical specification	HIMMEL®-Schneckengetriebemotor Getriebetyp / Type: CF10-G56S4 Maßbild / Dimension sheet: CF14/1369 Abtriebsdrehzahl / Output speed [1/min; 1/rpm]: 4.00//4.80 Übersetzung / Ratio [i]: 348.23 Farbe / colour: RAL 7035 Lichtgrau 2K / Light grey 2K-PUR Korrosivitätskategorie / corrosion protection: C1: i.A.a. DIN EN ISO 12944-2 Schichtdicke Lack/ paint layer thickness [µm]: 50-80 Schutzart / protection class: IP54 Bauform / mounting position: B5-01-B Abtriebsmoment / Output torque [Nm]: 41.9//34.9 Drehrichtung Abtrieb/Output direction of rotation: links / left Abtriebswelle Getriebe / Output shaft [mm; Zoll]: V18x40 Lagerung Getriebe / Bearing: zugeordnete Lagerung / assigned bearings Ölart / Oil type: CLP PG 460 Synth.oil Ölmenge / Oil quantity [l]: 0.22 Flansch-Durchmesser / Flange diameter [mm; Zoll]: A105 Wellenwerkstoff / Shaft material: ST60-2 Abdichtung Getriebe / Sealing: Wellendichtring (WDR) / shaft seal ring Elektrische Ausführung / Elektrical design: CE Polzahl / Poles: 4 Nennfrequenz / Nominal frequency [Hz]: 50//60 Nennspannung / Nominalvoltage [V]: 220-240/380-420//220-240/440-460 Schaltung / Wiring: S100//S100 (D/Y//D/Y) Nennleistung / Nominalpower [kW]: 0.06//0.06 Motordrehzahl nenn / Motor speed nom. [1/rpm]: 1380//1660 Nennstrom / Nominal current In [A]: 0.42/0.24//0.42/0.24 CosPhi / CosPhi: 0.68/0.70 KK-Lage / Terminal box position: 1C KK-Ausführung / Terminal box type: Kunststoff / plastic Wicklungsschutz / Motor protector: ohne / without Abtriebswelle Motor / Output shaft [mm; Zoll]: V11x24.5 Abdichtung Motor / Sealing motor: normal / normal Isolationsklasse / Insulation class: F Betriebsart / Duty type: S1 Lüfter / Fan: Kunststoff / plastic

You can find the current prices belongs to HIMMEL - CF10-G56S4 coded worm gear motor product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. Our company supply CF10-G56S4 referenced product fastest and securest on your request. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for CF10-G56S4 HIMMEL . Contact us if you are looking for alternative price of CF10-G56S4 .

Where can I buy CF10-G56S4 by HIMMEL in Macedonia?

You can purchase CF10-G56S4 by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the CF10-G56S4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Macedonia?

While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access CF10-G56S4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CF10-G56S4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CF10-G56S4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
