Prices Type MV 5224 RTK Regeltechnik Macedonia

BRAND	RTK Regeltechnik
Product	Type MV 5224
Internal code	ONR5087277
Weight	40
Technical specification	Replacement for W.Nr. 10062315/010 Motor control valve - MV 5224 series in three-way form for mixing nominal size DN 65, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: linear/- Mixing cone, metallic sealing Kvs value = 63 m³/h, stroke 15 mm Seat diameter 65 mm Surface treatment with zinc dust primer CE marking in accordance with Pressure Equipment Directive (PED) max. allowable pressure according to DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 30E-074 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor Setting speed 0.74 mm/s, stroke 15 mm Protection class IP 65 additional equipment: - additional limit switches (2 pieces) - Potentiometer 1000 ohms - RetranS2w type transmitter (2-wire) Output signal: 4.. 20 mA Effective direction: at 0% output port B to Drive spindle extended at 0% output

RTK Regeltechnik - Type MV 5224 referenced product produced by high technology.
Type MV 5224 became irreplaceable of foundations. We are one of the few companies which can present an offer for this product. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for Type MV 5224 RTK Regeltechnik . We present you the most competative price and delivery time on Type MV 5224 referenced product.

Where can I buy Type MV 5224 by RTK Regeltechnik in Macedonia?

You can purchase Type MV 5224 by RTK Regeltechnik from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the Type MV 5224?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in Macedonia?

While we are not the official distributor or seller of RTK Regeltechnik in Macedonia, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access Type MV 5224 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Type MV 5224 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for Type MV 5224?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
