Prices TPGC040088 Goudsmit Magnetics Macedonia

BRAND	Goudsmit Magnetics
Product	TPGC040088
Description	Cylinder
Internal code	ONR3826229
Weight	0.23
Technical specification	HGR-SQ-040-FP-R-M-S Switching : Pneumatic: 2 compressed air connections or: : 1 vacuum connection: see 'Gripper connection for vacuum control' (Document tab) Including : Vulcanized friction pad for extra grip and product protection Advised working load : 47 N Max. tear off force : 140 N Min. advised sheet thickness : 2 mm Interface/connection dim's : Threaded hole M8 : Threaded hole M5 (4x) Connections : Pneumatic: M5 (2x) Material friction pad/ring : NBR 60° Shore A Material housing : Aluminium : AISI316L (SS 1.4404) (screw cap) Surface treatment/finishing : Anodized Colour : Red Min./max. ambient temperature : 0 to 70 °C Switching pressure : Vacuum pressure -0.3 bar (switch on) : 4 bar (recommended), 6 bar (max.) Air consumption: 0.040 l/cycle (1x up, 1x down) Magnetic system : 4 Permanent magnet poles Magnet quality : Neodymium GSN-45, Br 13,700 gauss (at 20 °C), Tmax. 80 °C Depth : 46 mm Width : 46 mm Height : 63 mm

Goudsmit Magnetics - TPGC040088 referenced Cylinder product produced by high technology.
TPGC040088 is the result of a far more developed technology compared to similar regular products. All of the listed products are with guaranteed origin and high quality. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for TPGC040088 please contact us.

Where can I buy TPGC040088 by Goudsmit Magnetics in Macedonia?

You can purchase TPGC040088 by Goudsmit Magnetics from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the TPGC040088?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Goudsmit Magnetics in Macedonia?

While we are not the official distributor or seller of Goudsmit Magnetics in Macedonia, we source our products from reliable channels and offer you original Goudsmit Magnetics equipment at competitive prices.

How can I access TPGC040088 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for TPGC040088 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for TPGC040088?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
