Prices TL3B0-LP Mecon Macedonia

BRAND	Mecon
Product	TL3B0-LP
Internal code	ONR4976362
Custom code	90269000
Technical specification	Bypass flow meter for Turbo-Lux 3 set (spare part) workings Measurement principle: Bypass meter (floating body) Installation position: vertical Measurement accuracy Measurement deviation: ±2.0% of the end value of the measurement range (FM) ± 5.0% of measurement value (LPCB) ±2.5% of the final measurement range value (vDS) process conditions Nominal size: 8"/DN 200 (ø 219.1 mm) Pump rated power: 1500 usGpm Display range: 600 — 3000 usGPM 2200 - 11000 lpm operating conditions Medium: water Operating temperature: +4 to +50 °C max. operating pressure: FM 500 psi (34.5 bar) LPCB/ VdS PN 16 (232 psi) Constructive structure Differential pressure collection tube: brass Floater: stainless steel Side flow valve: stainless steel Filter screen: stainless steel Seal: NBR Certificates/Approvals FM LPCB VdS Stat. Item no.: 90269000 Country of origin: Federal Republic of Germany AL: N ECCN: N PREF-J: ALL

Mecon - TL3B0-LP referenced product produced by high technology.
TL3B0-LP became irreplaceable of foundations. TL3B0-LP referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on TL3B0-LP referenced product.
