| BRAND | S+S REGELTECHNIK |
| Product | 1101-7051-5021-000/ TF54 NTC10K |
| Description | Immersion temperature sensor |
| Internal code | ONR4993679 |
| Weight | 0.5 |
| Technical specification | Temperature data points [°C] Sensors/Perfect Sensor Protection output Temperature measurement range —35... +150 °C Measurement range —35... +180 °C (Max NTC = +150°C, Max LM235Z = +125°C) Process connection via immersion sleeve or mounting flange (accessory) insulation resistance 100 MΩ, at +20 °C (500 V DC) Stainless steel protection pipe, 1.4571, V4A, Ø = 6 mm electrical connection 0.14 - 2.5 mm², via screw terminals, Permissible humidity on ceramic base < 95% RH, non-condensing air Safety class III (according to EN 60 730) NTC10kOhm sensor Circuit type 2-wire connection Measurement current < 2.0 mW metal pressure screw cable connection (M 20 x 1.5); optionally with brass cable screw connection, nickel-plated (M 20 x 1.5; with strain relief, replaceable, inner diameter 6 - 12 mm) or M12 connectors in accordance with DIN EN 61076-2-101 (on request) connection head Form B, material aluminum, color white aluminum (similar to RAL 9006), Ambient temperature —20... +100 °C Protection class IP 54 (according to EN 60 529) standard IP 65 (according to EN 60 529) optional standards CE compliance, electromagnetic compatibility in accordance with EN 61326, according to EMC Directive 2014/ 30/EU |
Where can I buy 1101-7051-5021-000/ TF54 NTC10K by S+S REGELTECHNIK in Macedonia?
You can purchase 1101-7051-5021-000/ TF54 NTC10K by S+S REGELTECHNIK from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the 1101-7051-5021-000/ TF54 NTC10K?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of S+S REGELTECHNIK in Macedonia?
While we are not the official distributor or seller of S+S REGELTECHNIK in Macedonia, we source our products from reliable channels and offer you original S+S REGELTECHNIK equipment at competitive prices.
How can I access 1101-7051-5021-000/ TF54 NTC10K catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1101-7051-5021-000/ TF54 NTC10K on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1101-7051-5021-000/ TF54 NTC10K?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
