Prices MI-DM0165 DM1653-AAA06A0E0DGA-457mm Interroll Macedonia

BRAND	Interroll
Product	MI-DM0165 DM1653-AAA06A0E0DGA-457mm
Internal code	ONR4448661
Weight	50
Custom code	84313900
Technical specification	Ser.No. 12231701 Product name DM 0165 asynchronous 3-phase Protection grade IP 69K Pipe length (SL) 450.0 mm Drum width (FW) 457.0 mm Installation length (EL/LW/BF) 490.0 mm Axis total length (AGL) 580.0 mm power 2,200 W Number of poles winding 2 Torque [Nm] 139.5 Tension force 1.701 N Gear ratio (i) 19.64 Gearbox cast iron material designation: GGG-40 velocity at frequency 1 1,24 m/s frequency 1 50 Hz external connection diagram M45 high voltage 400 V low voltage 230 V Rated current, high voltage 4.55A Rated current, low voltage 7.85A velocity at frequency 2 1,49 m/s frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Tube material steel: St37-2 /AISI 1015 Tube diameter (A) 164.0 mm Tube diameter (B) 162.0 mm Tubular shape crowned (standard) Lid A, standard design Lid B standard design Lid A Material ALU: EN-AC43400/AL239 Lid B Material ALU: EN-AC43400/AL239 Shaft A version standard Ø40mm Shaft B version standard Ø40mm Shaft A material stainless steel: 1.4305/303 Shaft B material stainless steel: 1.4305/303 shaft A diameter (D) 40,0 mm Shaft B diameter (D) 40,0 mm Wave A final area size (F) 30.0 mm Shaft B final area width (F) 30.0 mm Shaft A final surface length (C) 45.0 mm Shaft B final surface length (C) 45.0 mm Oil type mineral oil Electrical connection terminal box electric. Connection material ALU Alsi10mg (Fe)/AL239

Interroll - MI-DM0165 DM1653-AAA06A0E0DGA-457mm referenced product produced by high technology.
MI-DM0165 DM1653-AAA06A0E0DGA-457mm is the result of a far more developed technology compared to similar regular products. It distinguishes with price and quality among the similar products. Our company can make an offer even if we do not distributor of Macedonia. MI-DM0165 DM1653-AAA06A0E0DGA-457mm referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy MI-DM0165 DM1653-AAA06A0E0DGA-457mm by Interroll in Macedonia?

You can purchase MI-DM0165 DM1653-AAA06A0E0DGA-457mm by Interroll from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the MI-DM0165 DM1653-AAA06A0E0DGA-457mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in Macedonia?

While we are not the official distributor or seller of Interroll in Macedonia, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0165 DM1653-AAA06A0E0DGA-457mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0165 DM1653-AAA06A0E0DGA-457mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0165 DM1653-AAA06A0E0DGA-457mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
