Prices MV 5274, DN 32 RTK Regeltechnik Macedonia

BRAND	RTK Regeltechnik
Product	MV 5274, DN 32
Description	modulating valves
Internal code	ONR4745012
Weight	9
Custom code	84818059
Technical specification	Engine Control Valve - MV 5274 Series in three-way shape for mixing, with short B-flange Nominal diameter DN 32, nominal pressure PN 16 Housing material Ductile iron EN-GJS-400-18-LT flanges with sealing surface in accordance with DIN Spindle sealing: Bellows with PTFE safety stuffing box Characteristic/Anstrom.: linear/- mixing cone, metallic sealing Kvs value = 15 m³/h, stroke 15 mm seat diameter 32 mm Surface treatment with zinc dust primer CE mark in accordance with Pressure Equipment Directive (PED) max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electric actuator - type ReAct 30E-074 actuating force 3 kN, including manual adjustment AC motor 230 V, 50/60 Hz Adjustment speed 0.74 mm/s, stroke 15 mm Protection class IP 65 - additional limit switches (2 pieces)

RTK Regeltechnik - MV 5274, DN 32 referenced modulating valves product produced by high technology.
You can provide the all references you look for in endustrial accessories in our company with our unique product range. Our company supply MV 5274, DN 32 referenced product fastest and securest on your request. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy MV 5274, DN 32 by RTK Regeltechnik in Macedonia?

You can purchase MV 5274, DN 32 by RTK Regeltechnik from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the MV 5274, DN 32?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in Macedonia?

While we are not the official distributor or seller of RTK Regeltechnik in Macedonia, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access MV 5274, DN 32 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MV 5274, DN 32 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MV 5274, DN 32?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
