Prices MI-DM0080 DM0803-AAC01B0E0FJD-300mm Interroll Macedonia

BRAND	Interroll
Product	MI-DM0080 DM0803-AAC01B0E0FJD-300mm
Internal code	ONR4580961
Weight	6.53
Technical specification	Product name DM 0080 Asynchronous 3-phase IP 69K degree of protection Tube length (SL) 293.0 mm Drum width (FW) 300.0 mm Installation length (EL/LW/BF) 305.0 mm Overall axle length (AGL) 330.0 mm power 140 W winding number of poles 2 Torque [Nm] 8.9 strip tensile force 219 N Gear ratio (i) 20.27 gearbox material designation steel: 16MnCr5/AISI 5115 Velocity at frequency 1 0.59 m/s Frequency 1 50 Hz external connection diagram M34 high voltage 400 V low voltage 230 V Rated current, high voltage 0.38 A rated current, low voltage 0.65 A Velocity at frequency 2 0.72 m/s Frequency 2 60 Hz high voltage 2 460 V low voltage 2 230 V Tube material stainless steel: 1.4301/304 Pipe diameter (A) 81.5 mm Tube diameter (B) 80.5 mm Pipe shape crowned (standard) Lid A design standard Lid B version standard Lid A material aluminium: EN-AC43400/AL239 lid B material aluminium: EN-AC43400/AL239 Shaft A version standard Ø17mm Shaft B version standard Ø17mm Shaft A Material stainless steel: 1.4305/303 Shaft B Material stainless steel: 1.4305/303 Shaft A Key.Area width (F) 13.5 mm Shaft B Key.Area width (F) 13.5 mm Wave A key. Face length (C) 12.5 mm Wave B key. Face length (C) 12.5 mm Oil type synthetic food oil Electrical connection straight screw connection electric. Connection material brass CuZn39Pb3/MS58 Power cable length 5.0 m Power cable type unshielded; non-halogen free

Interroll - MI-DM0080 DM0803-AAC01B0E0FJD-300mm referenced product produced by high technology.
MI-DM0080 DM0803-AAC01B0E0FJD-300mm is the result of a far more developed technology compared to similar regular products. Our company supply MI-DM0080 DM0803-AAC01B0E0FJD-300mm referenced product fastest and securest on your request. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy MI-DM0080 DM0803-AAC01B0E0FJD-300mm by Interroll in Macedonia?

You can purchase MI-DM0080 DM0803-AAC01B0E0FJD-300mm by Interroll from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the MI-DM0080 DM0803-AAC01B0E0FJD-300mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in Macedonia?

While we are not the official distributor or seller of Interroll in Macedonia, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0080 DM0803-AAC01B0E0FJD-300mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0080 DM0803-AAC01B0E0FJD-300mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0080 DM0803-AAC01B0E0FJD-300mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
