| BRAND | HIMMEL |
| Product | KP75-M/2 / 2140002369 |
| Description | flat motor |
| Internal code | ONR4940791 |
| Weight | 40 |
| Technical specification | Hydro-format system Same as type plate number P-852247/20 Ambient temperature/Ta [°C] +55 Electrical version/Elektrical design ccSaus Code letter L/J Number of poles/Poles 2 Output/ Power [kW] 7.5/10.0 Performance/Power [HP] 10.0/13.4 Engine speed/ engine speed [1/min; 1/rpm] 5910/5870 Frequency/ Frequency [Hz] 100/100 Number of phases 3~ Voltage/Voltage [V] 380-420/380-420 Current/Current [A] 13.9/18.0 CosPHi/CosPHI 0.89/0.92 Circuit/Wiring S101 (Y) Operating mode/Duty type S1/S 6-60% Operating mode/Duty type CSA/UL duty cont/int. duty S6 5sec. on 3 sec.off Dimension sheet: 1NJ009729 K model series/design series: K75 Type/type: KP75-M/2 K-size sheet/dimension sheet: 1NJ009729 Color/colour: RAL 7043 textured paint B/Structure lacquer B Design/mounting position: B3 K-mounting sides: one-sided foot machining Protection class: IP54 K-rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Rating plate logo/name plate logo: Homag Customs tariff number/HS code: 85015230 Ambient temperature/ Ambient temperature /Ta [°C]: -20/+45 Output variant: Hydro-format system W.diameter/shaft diameter [mm]: 40 W. length/shaft length [mm]: 75 (free shaft end) Wave thread/shaft thread: M14-R.H. Arrest/Detent: AS - position 2 Bearing AS/Bearing-AS (DE): High-precision bearing pair/Super-Precision Bearing pair Bearing BS/Bearing-BS (NDE): simple bearing KK version/Terminal box type: angled plug 723 KK location/Terminal box position: 2BK Label/Approval|Identification/Certification: CE & ccsAUS Number of phases: 3~ Code letter: K/G Number of pins/Poles: 2 Rated power/nominal power [kW]: 8.0/11.0 Rated power/ Nominal power [HP]: 10.7/14.7 Nominal motor speed/Nominal motor speed [1/min; rpm]: 5900/5850 Rated frequency/ Nominal frequency [Hz]: 100//100 Rated voltage/nominal voltage [V]: 380-420/380-420 Rated current/Nominal current In [A]: 14.8/19.8 CosPhi/CosPHI: 0.90/0.93 Circuit/ Wiring: S101 (Y) Operating mode/Duty type: S1/S 6-60% Operating mode/Duty type CSA/UL: duty cont/int. duty S6 5sec. on 3 sec.off Supply type/power supply: FU-operation/ inverter duty Supply type/power supply CSA/UL: inverter duty Drive protection/motor protection (IEC60034-25): to be guaranteed by system managers/to be Guaranteed by System Manager Winding protector/ Motor protector: WT 130°C Insulation class: F Ventilation type CSA/UL: TEFC Motor circuit diagram/Motor connection diagram: A1101104 |
Where can I buy KP75-M/2 / 2140002369 by HIMMEL in Macedonia?
You can purchase KP75-M/2 / 2140002369 by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the KP75-M/2 / 2140002369?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in Macedonia?
While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access KP75-M/2 / 2140002369 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for KP75-M/2 / 2140002369 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for KP75-M/2 / 2140002369?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
