BRAND	HIMMEL technologies
Product	2140001619 - KP75-L/2-M12K M16-RH-ATEX
Description	HIMMEL® flat motor
Internal code	ONR4903681
Weight	60
Custom code	85015230
Technical specification	*Electrical version based on CSA Dimension sheet: 1NJ000299 K model series/design series: K75 Type/type: KP75-L/2-M12K K-size sheet/dimension sheet: 1NJ000299 Color/colour: RAL 6011 Reseda green 2K/Reseda green 2K PUR Design/mounting position: B3 K-mounting sides: double-sided foot machining Protection class: IP64 K-rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Rating plate logo/name plate logo: SKY Flat motor according to ATEX/flat-motors acc. to ATEX: II 3D Ex tc IIIB T300°C Dc - IP64 max. radial force/max. radial forces/Fr [N]: 1200 Ambient temperature/ Ambient temperature /Ta [°C]: -20/+40 Output variant: Quick clamping system/Quick change clamping system W.diameter/shaft diameter [mm]: 30 W. length/shaft length [mm]: 103 (center foot hole to start tool/center foot hole to beginning of tool) Wave thread/shaft thread: M16-R.H. K-flange plates Ø/ external diameter flange [mm]: 140 K tool width [mm]: 0 - 5 Tool carrying/tool-lorry: 2 pins D=8 on LK=60 Storage AS/Bearing-AS (DE): Double bearing/Double bearing Bearing BS/Bearing-BS (NDE): simple bearing K-elect.connection type/elec. connection mode: terminal box/ terminal box KK material/Terminal box material: aluminum/aluminum KK location/Terminal box location: 1BK/3BK KK screw connection/gland: (2x) -M25x1.5 + (1x) -M16x1.5 + (3x) -M12x1.5 Label/Approval\|Identification/Certification: CE Manufacturing method/Type of production: Version according to [CSA] without approval/Execution to [CSA] without approval Number of phases: 3~ Number of pins/Poles: 2 Rated power/ Nominal power [kW]: 9//13.2 Rated power/ Nominal power [HP]: 12.1//17.7 Nominal motor speed/Motor speed nom. [1/min; rpm]: 3500//7000 Rated frequency/ Nominal frequency [Hz]: 60//120 Rated voltage/nominal voltage [V]: 254/440//440 Rated current/Nominal current In [A]: 28.7/16.6//25.1 cosPHI/cosPHI: 0.87//0 Circuit/ Wiring: S100//S102 (D/Y//D) Operating mode/Duty type: S 6-75% Operating mode/Duty type CSA/UL: int. duty S6 7.5 min on, 2.5 min off Type of supply/power supply: FU-operation/ inverter duty Supply type/power supply CSA/UL: inverter duty Drive protection/motor protection (IEC60034-25): to be guaranteed by system managers/to be Guaranteed by System Manager Winding protector/ Motor protector: PTC 130°C Insulation class: F Ventilation type CSA/UL: TEFC Motor circuit diagram/Motor connection diagram: A0100000 Circuit diagram built-in 1/Con. diagram compon. 1: A01TP000 Brake type/ Brake type: M12K [12Nm] (L8) Brake control voltage [V]: 415-506 Wiring/Connection: separate/separate Brake 1 circuit diagram/Brake connection diagram 1: A01BA000

HIMMEL technologies - 2140001619 - KP75-L/2-M12K M16-RH-ATEX referenced HIMMEL® flat motor product produced by high technology.
2140001619 - KP75-L/2-M12K M16-RH-ATEX became irreplaceable of foundations. 2140001619 - KP75-L/2-M12K M16-RH-ATEX referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. 2140001619 - KP75-L/2-M12K M16-RH-ATEX referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy 2140001619 - KP75-L/2-M12K M16-RH-ATEX by HIMMEL technologies in Macedonia?

You can purchase 2140001619 - KP75-L/2-M12K M16-RH-ATEX by HIMMEL technologies from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the 2140001619 - KP75-L/2-M12K M16-RH-ATEX?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL technologies in Macedonia?

While we are not the official distributor or seller of HIMMEL technologies in Macedonia, we source our products from reliable channels and offer you original HIMMEL technologies equipment at competitive prices.

How can I access 2140001619 - KP75-L/2-M12K M16-RH-ATEX catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 2140001619 - KP75-L/2-M12K M16-RH-ATEX on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 2140001619 - KP75-L/2-M12K M16-RH-ATEX?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
