| BRAND | HIMMEL |
| Product | K62-XL/2 M12 Re, 1C |
| Internal code | ONR3406277 |
| Weight | 25 |
| Technical specification | 2230000755 K-Modellreihe / Design series K62 Typ / Type K62-XL/2 K-Maßblatt / Dimension sheet 1NJ000036 Farbe / Colour RAL 5015 Himmelblau 2K / Sky blue 2K-PUR Bauform / Mounting position B3 Schutzart / Protection class IP54 K-Leistungsschild / Name plate Klebeschild 29x53 Leistungsschild Logo / Name plate Logo Himmel W.Durchmesser / shaft diameter 30,0 mm W.Länge / shaft-length 58,0 mm (mitte Fußbohrung bis Anfang Werkzeug) Wellengewinde / shaft thread M12 rechts K-Flanschscheiben Ø / external diameter flange 90 mm K-Werkzeugbreite / tool width max. 3 mm K-Werkzeugtyp / tool type Schnellspannsystem Werkzeugmitnahme / tool-lorry 2 Stifte D=8 auf LK=60 Lagerung AS / Bearing-AS Einfachlagerung / simple bearing Lagerung BS / Bearing-BS Einfachlagerung / simple bearing KK-Ausführung / Terminal box type Aluminium-M20x1.5 / aluminium-M20x1.5 KK-Lage / Terminal box position 1C Elektrische Ausführung / Elektrical design CE Polzahl / Poles 2 Leistung / Power [kW] 4.0 Motordrehzahl / Motor speed [1/min; 1/rpm] 2770 Frequenz / Frequency [Hz] 50 Phasenanzahl 3~ Spannung / Voltage [V] 400 Strom / Current [A] 8.50 CosPhi / CosPhi 0.82 Schaltung / Wiring S102 (D) Betriebsart / Duty type S6-60% Wicklungsschutz / Motor protector 3PTC`s 160°C Isolationsklasse / Insulation class F Ursprungsland/Country of origin: Germany AL: N ECCN: N |
Where can I buy K62-XL/2 M12 Re, 1C by HIMMEL in Macedonia?
You can purchase K62-XL/2 M12 Re, 1C by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the K62-XL/2 M12 Re, 1C?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in Macedonia?
While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access K62-XL/2 M12 Re, 1C catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for K62-XL/2 M12 Re, 1C on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for K62-XL/2 M12 Re, 1C?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
