Prices G052.005486.010.099.010 GSR Macedonia

BRAND	GSR
Product	G052.005486.010.099.010
Description	Solenoid valve
Internal code	ONR4061624
Custom code	84818073
Technical specification	for connection to 24V DC Reference V052.00 consists of: 052.005486 2/2-way solenoid valve Item Name: A5234/0604/.148-NG Control mode: direct-controlled, differential pressure at least 0 bar Design: Piston valve Function: NC - de-energized closed Connection: NPT 1/8 Seat: 3.0 mm Pressure: 0 - 20 bar Temperature (Medium) ፦20°C/+80°C Temperature (ambient) ፦20°C/+50°C Viscosity (max.): 22 mm²/sec Material (housing): stainless steel 1.4305 Material (media touched): Stainless steel 1.4104 Seal: PTFE Installation: Drive in upright or horizontal position Option: NG = NPT thread Explosion Protection: 2014/34/EU (ATEX) B0059.000006 solenoid Type: .148 (K0591410) Certification: PTB 03 ATEX 2172 X Gas: Ex II 2G Ex mb IIC T4 Gb Dust: Ex II 2D Ex mb tb IIIC T130°C Db Voltage: 24V DC Power: 10W Required protection: 1.0A acc. to IEC 60127-2-1 Degree of protection: IP65 Connection type: Powerful L=3m D=7mm Duty cycle: 100% Ambient temperature ፦20°C/+50°C Max. media temperature: +80°C

You can find the current prices belongs to GSR - G052.005486.010.099.010 coded Solenoid valve product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
