| BRAND | Schniewindt |
| Product | FLHK-012440-012441 |
| Internal code | ONR4443717 |
| Weight | 1 |
| Technical specification | CSN® flange radiators 96/F-27-440 Technical data: Supply voltage [V] 440.00 Number of switching stages 1 Output level 1 [kW] 27,000 Total power [kW] 27,000 Standard power tolerance (+5/-10%) Tol. related to hot output Upper warm tolerance (%) 5 Lower warm tolerance (%) -10 Star interconnection Neutral wire yes Protection class IP 54 Horizontal installation position Installation length [mm] 1360,0 Installation length upper tol. [mm] 0 Installation length lower tol. [mm] -35 Unheated length [mm] 170 Heating element type RHK number of RHK 9 Number of RHKs with reserve 9 Diameter [mm] Ø 11.5 mm Curved design Surface load [W/cm²] 3.49 Pipe material 1.4571 Stud material nickel-plated steel Type of fastening welded Closure type Giso-G Steel spacer Spacer pipe length [mm] 104 FLANGE NORM ASME B16.5 nominal diameter 6" Class 150 pressure rating Materials 1.4571 Deflection segment type Diameter [mm] 148.0 count 6 Fixation With, fixed to flange terminal box design/material CSN standard, steel, RAL 7035 Dimensions (W x H x D in mm) 300 x 300 x 160 Number of thermostats/sensors in heating bundle 1 Temperature detection type limiter Temperature detection limiter, 20/500°C, EM-5, 1000/6x280 mm Temperature detection interconnection external control Temperature detection indoor setting thermal bridge type pipe fittings brazed Thermal bridge length [mm] 120 interconnection stage 1 connection terminal potting interconnection Giso-G Control cabinet heating with Climate connector with Standard design, black Painting terminal box Standard execution Color (RAL) 7035 Old Part Number 7062331363274040988 Operating conditions: medium air Volumetric flow 2547.0 Volume flow unit Nm³/h Inlet temperature [°C] 45 outlet temperature [°C] 70 (TS) - design temperature min. [°C] -5 (TS) - design temperature max. [°C] 100 Ambient temperature min. [°C] 5 Max. ambient temperature [°C] 55 (PS) - maximum design pressure [bar] (g) 16.0 Pressure test required Yes (PT) test pressure [bar] (g) 23.0 Operating pressure [bar] (g) 12.0 classification according to the PED Article 4.3 AD 2000 standard |
Where can I buy FLHK-012440-012441 by Schniewindt in Macedonia?
You can purchase FLHK-012440-012441 by Schniewindt from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the FLHK-012440-012441?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Schniewindt in Macedonia?
While we are not the official distributor or seller of Schniewindt in Macedonia, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.
How can I access FLHK-012440-012441 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for FLHK-012440-012441 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for FLHK-012440-012441?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
