Prices ESW®- Compact 001 HOLTHAUSEN ELEKTRONIK Macedonia

BRAND	HOLTHAUSEN ELEKTRONIK
Product	ESW®- Compact 001
Description	Electronic vibration monitor
Internal code	ONR1838602
Weight	1.5
Custom code	90318080
Technical specification	Operating voltage 24V DC 5% Current consumption max. 100mA Temperature range 0 to 65°C Protection class IP 68 Stainless steel housing 1.4571/1.4404 Case dimensions 94x70 (h x Ø) Tightening torque max. 30 Nm, power transmission only via hexagon Weight approx. 1.0 kg (without cable), approx. 1.2 kg (with cable) Plexiglass inspection glass DIN 4102 IB2, s = 5mm Connection cable 2m, SD 90 C/ Kaweflex 6430 SK-C, 7 x 0.34mm², shielded, jacket material: PUR/PUR, min. bending radius: 50.25 mm/53.25 mm Cable fitting M16x1.5, CuZn39Pb3 brass, nickel-plated Lamellar insert: polyamide PA6 V-2 Sealing ring: CR/NBR polychloroprene nitrile rubber O-ring: nitrile rubber NBR Sensor integrated acceleration sensor Measurement variable Vibration Velocity in mm/s Measurement range 0 to 10/0 to 20/0 to 50mm/s, switchable RMS signal evaluation Frequency range 10Hz to 1kHz (-3dB) Butterworth filter, 60dB/dek or 18dB/oct Analog output 0 to 20mA or 4 to 20mA power source proportional to the set measurement range Load resistance max. 390ohm Switching outputs two potential-free switching contacts (30V, 1A) switching thresholds 10% to 100% of the measurement range, adjustable via potentiometer in the housing Response delay K 1 = 10s, K 2 = 5s Waste delay K 1 = 0.5s, K2 = 0.5s Line monitoring During normal operation, the relays are energized and the switching contacts are closed. In case of alarm, loss of voltage or if the cable breaks, the relays fall back into their rest position. Cable layout pink +Ub blue Dimensions yellow closer K1 green center contact K1 white closer K2 brown center contact K2 grey analog output Optional threaded pin, M8x25mm, V4A

HOLTHAUSEN ELEKTRONIK - ESW®- Compact 001 referenced Electronic vibration monitor product produced by high technology.
ESW®- Compact 001 became irreplaceable of foundations. ESW®- Compact 001 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on ESW®- Compact 001 referenced product.

Where can I buy ESW®- Compact 001 by HOLTHAUSEN ELEKTRONIK in Macedonia?

You can purchase ESW®- Compact 001 by HOLTHAUSEN ELEKTRONIK from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the ESW®- Compact 001?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HOLTHAUSEN ELEKTRONIK in Macedonia?

While we are not the official distributor or seller of HOLTHAUSEN ELEKTRONIK in Macedonia, we source our products from reliable channels and offer you original HOLTHAUSEN ELEKTRONIK equipment at competitive prices.

How can I access ESW®- Compact 001 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ESW®- Compact 001 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ESW®- Compact 001?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
