| BRAND | Schniewindt |
| Product | ERCU/25 - 3 - 400 |
| Description | Screw-in heater |
| Internal code | ONR4434397 |
| Weight | 0.85 |
| Technical specification | ERC-011847-007350 Supply voltage [V] 400.00 Total power [kW] 3,000 Standard power tolerance (+5/-10%) Tol. related to hot output Upper warm tolerance (%) 5 Lower warm tolerance (%) -10 Star interconnection Neutral wire yes Protection class IP 65 Horizontal installation position Installation length [mm] 250,0 Installation length upper tol. [mm] 0 Installation length lower tol. [mm] -30 Unheated length [mm] 35 screw connection G 1 1/2 - SW 65 Screw connection material brass number of RHK 3 Diameter [mm] diameter 8.5 mm Curved design surface load [W/cm²] 8.71 Pipe material 1.4404 Type of fastening soldered Closure type Giso-G hood Ø 80 x 80 mm Hood material galvanised steel Rotating bowl material nickel-plated brass M20 cable gland Cable gland material plastic Temperature detection type limiter Temperature detection limiter fix, 165 °C, stiebel, 350 mm, 3-pole Temperature detection interconnection Direct connection Temperature detection indoor setting Sensor protection tube diameter [mm] 10 Accessory (gasket, nut) With seal Material seal aramid (WS 3820, novapress UNIVERSAL, Aremi,...) Operating conditions: medium water (TS) - design temperature max. [°C] 100 (PS) - design pressure max. [bar] (g) 10.0 operating pressure [bar] (g) |
Where can I buy ERCU/25 - 3 - 400 by Schniewindt in Macedonia?
You can purchase ERCU/25 - 3 - 400 by Schniewindt from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the ERCU/25 - 3 - 400?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Schniewindt in Macedonia?
While we are not the official distributor or seller of Schniewindt in Macedonia, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.
How can I access ERCU/25 - 3 - 400 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ERCU/25 - 3 - 400 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ERCU/25 - 3 - 400?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
