| BRAND | Reer |
| Product | EOS4 1802 AH |
| Description | Hand Detection Safety Light Curtain |
| Internal code | ONR1949786 |
| Weight | 5.5 |
| Custom code | 85414090 |
| Technical specification | Safety level Type 4 - PL e Protected height (mm) 1810 Resolution (mm) 20 Controlled height (mm) 1800 Max. range (m) 20 Restart Automatic Functioning system Emitter / Receiver Safety level (SIL / PL) Type 4 - SIL 3 - SILCL 3 - PL e - Cat. 4 Operating temperature (°C) - 20 ... 55 Response time (ms) 23,5 Number of beams 180 Max. length of the connection cables (m) 100 Signalling LEDs for light curtain's status and diagnostics Safety output type 2 fail-safe PNP (400 mA at 24 VDC) with protection against short circuit, overload and reverse polarity Connections M12 5-pole connectors MTTFD (ISO13849) years 236,1 PFHD (IEC 61508) 2,57E-08 Safety outputs 2 OSSD PNP (400 mA at 24 VDC) Safety functions With external module Detection Hand Protective enclosures None Packaging dimensions HxLxW (mm) 145 x 1920 x 200 Product class C |
