Prices P/N: 202275 Type: DGBN-031-B (pack x20) Idec Macedonia

BRAND	Idec
Product	P/N: 202275 Type: DGBN-031-B (pack x20)
Description	Thumbwheel Switch
Internal code	ONR250866
Weight	0.2
Custom code	85365080
Technical specification	Front Size (H x W) 1.287" x 0.314" (33 x 8mm) Character Size (H x W) Decimal unit: 0.273" x 0.133" (7 x 3.4mm) Operator Style Set-lock, dual button, and thumbwheel Assembly Method Snap-fit Mounting Method Snap-fit Housing Color Black Character Color White characters on black background Terminal Style Solder Output 2-position repeat, decimal, binary coded decimal (BCD), duodecimal, and hexadecimal setting, and complementary BCD Connector Types Solder Operating Voltage 50V AC, 28V DC Operating Current 0.1A (resistive load) Thermal Current 1A (non-switching) Dielectric Strength Between live and dead parts: 1,000V AC, 1 minute Between live parts: 500V AC, 1 minute Insulation Resistance Between live and dead parts: 1,000MΩ min Between live parts: 10MΩ min Contact Resistance 200mΩ maximum Vibration Resistance 50m/sec2 (approximately 5G) maximum Shock Resistance 100m/sec2 (approximately 10G) maximum Life Expectancy (operations) Electrical: 100,000 minimum Mechanical: 1,000,000 minimum Operating Temperature –20 to +60°C (do not freezin

You can find the current prices belongs to Idec - P/N: 202275 Type: DGBN-031-B (pack x20) coded Thumbwheel Switch product. P/N: 202275 Type: DGBN-031-B (pack x20) became irreplaceable of foundations. It distinguishes with price and quality among the similar products. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for P/N: 202275 Type: DGBN-031-B (pack x20) Idec . Make an offer to us for P/N: 202275 Type: DGBN-031-B (pack x20) please contact us.
