| BRAND | Calectro |
| Product | CPS-D-A |
| Description | differential pressure transmitter |
| Internal code | ONR3366557 |
| Weight | 0.166 |
| Custom code | 90321020 |
| Technical specification | Calectro differential pressure transmitter-100... +3500 Pa with display The CPS-D-A pressure sensor has a built-in differential pressure element, which for a high Accuracy and linearity are temperature-compensated. The differential pressure element and the output signal have a high resolution, which means that the pressure value is in steps of max. 1 Pa over the entire Measurement range (-100 to + 3500Pa) is presented. The desired function and measurement range are determined by set an illuminated display. The pressure measurement range determines at which measurement value the Start the output signal and when the maximum output signal should be given. output signal (0- 10V or 4-20 mA), K factor for volume measurement and the desired signal attenuation are also set via the display. CPS-D-A is manufactured from the factory for differential pressure measurement in the range 0-500 Pa, 0-10V output signal and medium signal attenuation (10 sec.) delivered. The measurement range can be indiscriminate from - 100 Pa to +3500 Pa, in steps of 50 Pa. CPS-D-A can measure volume/flow rate by setting the kFactor using, for example, blowers or measurement panels. The conversion formula The differential pressure in volume is: q = k x?? p. The K factor can be set with two decimals become. In addition, various units can be set: m³/h, m³//s and l/s. The The unit setting is only a display label and therefore does not perform a mathematical calculation of Measurement off. The measurement range can be indiscriminately from 0 to 32000, in steps of 100 to 3500 and in Steps of 500 from 3500 can be set. TECHNICAL DATA Supply voltage: 24V AC/DC ± 10% power consumption: 43 mA Output signal: 0-10V (>5 k? imp.) /4-20 mA Average attenuation: 3.10 or 20 sec Pressure ranges: Adjustable from -100 to +3500 Pa, in steps of 50 Pa Volume ranges: adjustable from 0 to +32000, in steps of 100 to 3500 and in steps of 500 from 3500 - Selectable standard symbols on the display: m³/h, m³//sec or l/sec - K factor: 0-9999.99 Accuracy: Normally ± 1% of measured pressure (@ <-100 Pa/>+100 Pa) Display: graphical LCD with backlight Ambient temperature: -20 to +50°C Cable inputs: 1xM16, 5-10 mm cable dimensions (WxHxD): 78 x90x40 m Weight: 92g 2 m hose and 2 nipples Protection class: IP54 |
Where can I buy CPS-D-A by Calectro in Macedonia?
You can purchase CPS-D-A by Calectro from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the CPS-D-A?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Calectro in Macedonia?
While we are not the official distributor or seller of Calectro in Macedonia, we source our products from reliable channels and offer you original Calectro equipment at competitive prices.
How can I access CPS-D-A catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CPS-D-A on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CPS-D-A?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
