Prices CPS-A Calectro Macedonia

BRAND	Calectro
Product	CPS-A
Description	Differential pressure transmitter -50 - +3500 Pa
Internal code	ONR3306403
Weight	0.161
Custom code	90321020
Technical specification	CPS-A pressure sensor has a built-in differential pressure element, which helps to achieve high accuracy and Linearity is temperature-compensated. With a DIP switch, the desired pressure measurement range is discontinued. The output signal (0-10V or 4-20 mA) and the desired signal attenuation are also provided with set to the DIP switch. Housing terminal and cable connection (with pre-assembled M16 screws) can be removed, which simplifies installation. The housing cover has on the top edge a hinge and at the bottom a snap lock with locking hook, which closes the lid in When folded up, keeps it open. Supply voltage: 24V AC/DC ± 10% Power consumption: approx. 31 mA output signal: 0-10V/4-20 mA Pressure ranges: -50-50/0-100/-300/-500/-700/-1000/-200/1-3500 Pa Accuracy: Usually ± 1% of measured pressure Green LED: Lights continuously: normal operation Flashes: zero pressure calibration Ambient temperature: -20 to +50°C Cable inputs: 1xM16, 5-10 mm cable 2 m hose and 2 nipples Dimensions (WxHxD): 78x90x40 mm Protection class: IP54

You can find the current prices belongs to Calectro - CPS-A coded Differential pressure transmitter -50 - +3500 Pa product. CPS-A became irreplaceable of foundations. It distinguishes with price and quality among the similar products. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for CPS-A please contact us.

Where can I buy CPS-A by Calectro in Macedonia?

You can purchase CPS-A by Calectro from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the CPS-A?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Calectro in Macedonia?

While we are not the official distributor or seller of Calectro in Macedonia, we source our products from reliable channels and offer you original Calectro equipment at competitive prices.

How can I access CPS-A catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CPS-A on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CPS-A?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
