BRAND	C.E. srl
Product	CFIB - 2 - MA - 35H - ET -0 -0
Description	GLOBTOP CF series case mod. CFIB in aluminum alloy (copper ≤ 0.1%), with open/closed position indicator for rotary valves
Internal code	ONR4873391
Weight	2.5
Custom code	90330000
Technical specification	• ATEX certification (BVI 19 ATEX 0006): Ex II 2 GD — Ex db IIC T6/T5/T4 Ex tb IIIC T85/T100/T135°C (Tamb. from -50°C to +60/+80/+100°C) - Cable entry: No. 3 3/4" npt-f - Terminal block: 6 terminals plus ground connection (option 12 terminals) - Degree of protection: IP66/67/67M (with shaft rotation test) - Surface treatment: chromation (compliant with MIL5541 Class 1A) + polyester coating (RAL7000) (maximum resistance to chemical and atmospheric agents) - Position indicator: three-dimensional dome in red-green color - Shaft: namur coupling — 316 stainless steel material Each case is equipped with 2 GO SWITCH (TOPWORX) with the following characteristics: - passive type 30 Model 35 Hermetic magnetic limit switch (without power supply and without reed contacts) - mechanical contact (snap action & dry contact): gold-plated SPDT in silver-cadmium; hermetic - contact capacity: 4A ac 120V ac, 2A c.a 240V ac and 3A dc 24V DC resistive load - sensitive distance: 3 mm. (with iron seal) - differential (hysteresis): 3 mm. (with iron seal) - response time: 8 milliseconds - working temperature: see T.amb. of enclosure certification - housing: cupronickel - nr.4 PVC insulated connection conductors 105°C

C.E. srl - CFIB - 2 - MA - 35H - ET -0 -0 referenced GLOBTOP CF series case mod. CFIB in aluminum alloy (copper ≤ 0.1%), with open/closed position indicator for rotary valves product produced by high technology.
CFIB - 2 - MA - 35H - ET -0 -0 became irreplaceable of foundations. CFIB - 2 - MA - 35H - ET -0 -0 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. CFIB - 2 - MA - 35H - ET -0 -0 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy CFIB - 2 - MA - 35H - ET -0 -0 by C.E. srl in Macedonia?

You can purchase CFIB - 2 - MA - 35H - ET -0 -0 by C.E. srl from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the CFIB - 2 - MA - 35H - ET -0 -0?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of C.E. srl in Macedonia?

While we are not the official distributor or seller of C.E. srl in Macedonia, we source our products from reliable channels and offer you original C.E. srl equipment at competitive prices.

How can I access CFIB - 2 - MA - 35H - ET -0 -0 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CFIB - 2 - MA - 35H - ET -0 -0 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CFIB - 2 - MA - 35H - ET -0 -0?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
