Prices CF10-G56S4 HIMMEL Macedonia

BRAND	HIMMEL
Product	CF10-G56S4
Description	worm gear motor
Internal code	ONR4729821
Weight	9
Custom code	85015100
Technical specification	Dimension sheet: CF14/1369 Transmission design/Type: HIMMEL® worm gear motor/HIMMEL® -worm Gear Transmission type/Type: CF10-G56S4 Dimension picture/Dimension sheet: CF14/1369 Output speed [1/min; 1/rpm]: 4.00//4.80 Translation/Ratio [i]: 348.23 Color/colour: RAL 7016 anthracite grey 2K/Anthracite grey 2K-PUR Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP54 Model/mounting position: B5-01-B Output torque [Nm]: 41.9//34.9 Direction of rotation: left/left [CCW] Output shaft transmission/Output shaft [mm; inch]: V18x40 Gearbox bearing: associated bearing/assigned bearings Oil type/Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.22 Flange diameter/flange diameter [mm; inch]: A105 Shaft material/Shaft material: C45 Transmission sealing/Sealing: shaft seal (WDR)/shaft seal ring Electrical version/Electrical design: CE Number of poles/Poles: 4 Nominal frequency/ Nominal frequency [Hz]: 50//60 Nominal voltage/Nominal voltage [V]: 220-240/380-420//220-240/440-460 Circuit/Wiring: S100//S100 (D/Y//D/Y) Rated power/ Nominal power [kW]: 0.06//0.06 Name motor speed/ Motor speed name [1/rpm]: 1380//1660 Current/Nominal current In [A]: 0.42/0.24//0.42/0.24 cosPHI/cosPHI: 0.68/0.70 KK location/Terminal box position: 1C KK version/Terminal box type: plastic/plastic Winding protection/Motor protector: without/without Output shaft Motor/ Output shaft [mm; inch]: V11x24.5 Engine sealing/Sealing motor: normal/normal Insulation class/Insulation class: F Operating mode/Duty type: S1 Fan/Fan: plastic/plastic

HIMMEL - CF10-G56S4 referenced worm gear motor product produced by high technology.
CF10-G56S4 became irreplaceable of foundations. We are one of the few companies which can present an offer for this product. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. CF10-G56S4 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy CF10-G56S4 by HIMMEL in Macedonia?

You can purchase CF10-G56S4 by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the CF10-G56S4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Macedonia?

While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access CF10-G56S4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CF10-G56S4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CF10-G56S4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
