Prices CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB CD AUTOMATION Macedonia

BRAND	CD AUTOMATION
Product	CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB
Description	thyristor plate series S
Internal code	ONR1867584
Weight	0.6
Technical specification	CD3S10035480024SSRHB Circuit: single phase switch, zero through switch - load current: 35 A (T40°C), 28A (T50°C) - Load voltage: up to 480 V - auxiliary voltage: 12-24 V - Control: logic 4-30 Vdc, 12 mA max. (OFF < 1 Vdc, ON > 4 Vdc) - partial load error: * partial load fault detection from 50msec. switch-on time * partial load fault detection from 80% of Nominal current * automatic measurement of the nominal current by means of a button at 100% adjustment size for approx. 1 min. - Dimensions: 52 x 120 x 120 mm (WxHxD) - ideal for heating control with ohmic load (zero passage) - antiparallel thyristor actuators - CE mark - space-saving thanks to integrated heatsink - RC link and varistor integrated - LED status indicator - DIN rail mounting or screw mounting - incl. Current transformer 50/0,05A for DIN rail mounting

You can find the current prices belongs to CD AUTOMATION - CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB coded thyristor plate series S product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB referenced product.

Where can I buy CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB by CD AUTOMATION in Macedonia?

You can purchase CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB by CD AUTOMATION from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of CD AUTOMATION in Macedonia?

While we are not the official distributor or seller of CD AUTOMATION in Macedonia, we source our products from reliable channels and offer you original CD AUTOMATION equipment at competitive prices.

How can I access CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
