Prices CAT-230V Calectro Macedonia

BRAND	Calectro
Product	CAT-230V
Description	Analogue universal thermostat
Internal code	ONR4873395
Weight	0.25
Technical specification	Calectro analog universal thermostat for PT1000 and NTC sensors CAT is an analog universal thermostat for all types of single-stage temperature control between -10 and + 50° C, e.g. for underfloor heating and frost protection. CAT is supplied with 230 V AC and has a potential relay without alternating current (16 A, 250 V) The thermostat can be used together with a Pt1000 or an NTC sensor (the same type like the previous Calectro thermostats). It is therefore backwards compatible with parts of the earlier Calectro thermostat programs. The hysteresis (coupling difference) centered above the target value can be adjusted between 1 and 10° C. example: Set point 20° C and hysteresis 1° C. The relay switches the heater on at 19.5° C and off at 20.5° C. CAT has an energy saving feature that lowers the set point by 4°C when terminals 9 and 12 are connected Be short-circuited, e.g. with a timer. TECHNICAL DATA Supply voltage: 230 V AC ± 10% 50-60 Hz Power consumption: max 4.5 W Relay output: 16 A, 250 V potential-free contact Temperature range: -10 to + 50° C Hysteresis: 1-10°C Reduction saving: 4°C Selectable temperature sensors: Pt1000 and NTC (Calectro type: 22/33/44/55/99) Fine-tuning the temperature: -5 to + 5° C LEDs - Green continuous light: power indicator - Green flashes: sensor fault - Yellow: relay activated/ heating switched on Ambient temperature: 0-50°C Assembly: DIN rail, standard housing Approval: CE Dimensions WxHxD: 52.5x86x62 mm Housing class: IP20

Calectro - CAT-230V referenced Analogue universal thermostat product produced by high technology.
CAT-230V became irreplaceable of foundations. CAT-230V referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Contact us if you are looking for alternative price of CAT-230V .

Where can I buy CAT-230V by Calectro in Macedonia?

You can purchase CAT-230V by Calectro from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the CAT-230V?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Calectro in Macedonia?

While we are not the official distributor or seller of Calectro in Macedonia, we source our products from reliable channels and offer you original Calectro equipment at competitive prices.

How can I access CAT-230V catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CAT-230V on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CAT-230V?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
