Prices 95F/RC-Exdet1,5T3/T200´C Schniewindt Macedonia

BRAND	Schniewindt
Product	95F/RC-Exdet1,5T3/T200´C
Description	CSN Ex-Tauchheizkörper
Internal code	ONR3358350
Weight	20
Custom code	85161080
Technical specification	Ex classification --- Type designation 95F/RC-Exdet.. T./T... °C Type test certificate 1 BVS 15 ATEX E 143 X Type test certificate 2 Certificate of Conformity IECEx BVS 15.0117X Ignition protection type Ex det Area of application Zone 1 and Zone 21 Note on Zone II 2G Ex db eb IIC T3 Gb-ii2d Ex tb IIIC T200°C Db Permitted Ambient temperature min./max. (°C) -40/+40 at the connection head Version 1 - threaded flange without cooling section Order IV Temperature class T3 -------- Technical part -------- Drawing number 20356100 Circuit diagram No. 416028 Total power (kW) 1.50 Output tolerance (hot output) standard (+5%/-10%) Connection voltage (V) 400.00 Star connection Levels 1 Output level 1 (kW) 1.50 Protection class (IP) IP 66 Installation position horizontal Material certificates Without material certificates -------- heating element -------- Heating element type tubular heater Mounting type heating elements soldered Giso tubular heater lock Number of heating elements (pieces) 6 Installation length (mm) 250.0 unheated length (mm) 50.0 Tubular heater diameter Ø 8.5 mm Material tubular heater 2.4858/Alloy 825 Cooling line Without cooling section Surface load (W/cm²) 2.34 -------- Thermostat -------- Temperature controller (°C) 1-pole 0-100°C Temperature limiter (°C) 1-pole 0-150°C Limiter set to (°C) 40 Controller/limiter connection unconnected --- Radiator mount --- G2 1/2" thread Thread material 1.4541/AISI 321 Type of spacer spacer wheel Number of spacers (pieces) 2 --- Connection hood/terminal box --- GGG40.3 connector hood painted Cable connector 1 M20 Material cable connector 1 Nickel-plated brass Cable connector 2 M20 Material cable connector 2 Nickel-plated brass --- Operating condition --- Medium water Operating temperature [°C] 20 Permissible min/max temperature TS (°C) Permissible min. temperature TS °C 5 Permissible max. temperature TS °C 40 max. allowable Pressure PS (bar g) 0.500 Novapress Universal seal

You can find the current prices belongs to Schniewindt - 95F/RC-Exdet1,5T3/T200´C coded CSN Ex-Tauchheizkörper product. You can ask all the codes and references except 95F/RC-Exdet1,5T3/T200´C too. 95F/RC-Exdet1,5T3/T200´C referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Make an offer to us for 95F/RC-Exdet1,5T3/T200´C please contact us.

Where can I buy 95F/RC-Exdet1,5T3/T200´C by Schniewindt in Macedonia?

You can purchase 95F/RC-Exdet1,5T3/T200´C by Schniewindt from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the 95F/RC-Exdet1,5T3/T200´C?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Schniewindt in Macedonia?

While we are not the official distributor or seller of Schniewindt in Macedonia, we source our products from reliable channels and offer you original Schniewindt equipment at competitive prices.

How can I access 95F/RC-Exdet1,5T3/T200´C catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 95F/RC-Exdet1,5T3/T200´C on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 95F/RC-Exdet1,5T3/T200´C?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
