Prices (SC11K)-M1P4/2U / 2010000168 HIMMEL Macedonia

BRAND	HIMMEL
Product	(SC11K)-M1P4/2U / 2010000168
Description	mounting motor
Internal code	ONR4934726
Weight	12
Custom code	85015100
Technical specification	Special features: KAWEFLEX connection cable 7x1x18m Product number: 85015100 Weight: 12 kg Dimension sheet: SC16/4505 Transmission type/Type: HIMMEL® mounting motor/HIMMEL® flange-mounted engine Transmission Type/ Type: (SC11K) -M1P4/2U Dimension sheet: SC16/4505 Output speed/ Output speed [1/min; rpm]: 1430.00/2870.00 Color/colour: RAL 9011 graph-black, matt 2K/graphite black 2K PURE Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP66 Design/mounting position: B5 Direction of rotation: right/right [CW] Label/Approval\|Identification/Certification: CE Number of poles/poles: 4/2 Rated frequency/ Nominal frequency [Hz]: 50 Rated voltage/nominal voltage [V]: 380-420 Circuit/ Wiring: S300 (D/YY) Rated power/nominal power [kW]: 0.2/0.3 Nominal motor speed/Nominal motor speed [1/min; rpm]: 1430/2870 Rated current/Nominal current In [A]: 0.75/0.65 CosPhi/CosPHI: 0.69/0.88 KK location/Terminal box position: 2D KK version/Terminal box type: aluminum/aluminum Winding protection/Motor protector: ohne/without Motor output shaft/Output shaft [mm; inch]: V10x16.5 Sealing motor/Sealing motor: normal/normal Insulation class: F Operating mode/Duty type: S 3-75% Fan/Fan: without/non-ventilated

HIMMEL - (SC11K)-M1P4/2U / 2010000168 referenced mounting motor product produced by high technology.
(SC11K)-M1P4/2U / 2010000168 became irreplaceable of foundations. Our company supply (SC11K)-M1P4/2U / 2010000168 referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy (SC11K)-M1P4/2U / 2010000168 by HIMMEL in Macedonia?

You can purchase (SC11K)-M1P4/2U / 2010000168 by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the (SC11K)-M1P4/2U / 2010000168?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Macedonia?

While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access (SC11K)-M1P4/2U / 2010000168 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for (SC11K)-M1P4/2U / 2010000168 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for (SC11K)-M1P4/2U / 2010000168?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
