Prices 54 E 625 / S 2 T 0 (Article nr. 700.934) Combimac Macedonia

BRAND	Combimac
Product	54 E 625 / S 2 T 0 (Article nr. 700.934)
Description	Cenfrifugal fan
Internal code	ONR4063883
Weight	61
Technical specification	Technical details fan Article nr. 700.934 Type 54 E 625 / S 2 T 0 Design (ISO 13348 & 12499) = Type high pressure Description gas tight - belt driven Fan materials = Impeller stainless steel Housing cast iron Impeller materials Blade AISI316 Hub AISI316 Medium = Type biogas Temp. Max. 60 °C Dimensions/Drawing = B.004.250 as built Mass (appr.) 185 kg Paint sytem = Inside 2-comp. epoxy Outside Blue, RAL5017 Position = 1 L Possible Pos. 1-2-3-4L / 1-2-3-4R Speed range = >3000 rpm Belt drive - belt discs ratio = 140 M Impeller speed 3999 rpm Graph type (ISO 5167-1 & 2) = Graph nr. 185 ATEX applicable Inside: Outside: Zone 2 = Ɛx II 3G/3G Ex h IIB T3 Gc/Gc Ɛx II 3G/3G Ex h IIB T3 Gc/Gc Standard = ISO 80079-36 & 37 Leakage test CN 3022 Guideline NEN-EN 14986 Cond.-drain Technical details electric motor Article nr 338.439 Supply voltage (IEC 60092) = 400V 3ph 50 Hz Classification not applicable Power rating (IEC 60034-1) = 4,6 kW PTC included Duty Cycle (IEC 60034-1) = S1 Insulation class F Rise B Connection (IEC 60034-12) = Delta Number of Poles = 2 FCU not applicable Speed (synchronous) = 3000 IP (IEC 60034-5) = IP55 Execution (IEC 60034-7) = IM B3 Efficiency - Frame size (IEC 60072-1) = 132S Mass (appr.) 61 kg Ambient temperature = Min. 0 Max. 40 °C ATEX Ɛx II 2G Ex eb IIC T3 Gb ATEX standards = IEC 60079-0:2017 IEC 60079-7:2015 (ec) ATEX certification = Directive 2014/34/eu Chapter 3

Combimac - 54 E 625 / S 2 T 0 (Article nr. 700.934) referenced Cenfrifugal fan product produced by high technology.
If you need other products from Combimac, please send us an inquiry by e-mail. 54 E 625 / S 2 T 0 (Article nr. 700.934) referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy 54 E 625 / S 2 T 0 (Article nr. 700.934) by Combimac in Macedonia?

You can purchase 54 E 625 / S 2 T 0 (Article nr. 700.934) by Combimac from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the 54 E 625 / S 2 T 0 (Article nr. 700.934)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Combimac in Macedonia?

While we are not the official distributor or seller of Combimac in Macedonia, we source our products from reliable channels and offer you original Combimac equipment at competitive prices.

How can I access 54 E 625 / S 2 T 0 (Article nr. 700.934) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 54 E 625 / S 2 T 0 (Article nr. 700.934) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 54 E 625 / S 2 T 0 (Article nr. 700.934)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
