Prices Nr. 504616.06 Type C10-G56M4 HIMMEL Macedonia

BRAND	HIMMEL
Product	Nr. 504616.06 Type C10-G56M4
Description	worm gear motor
Internal code	ONR4718326
Weight	8
Technical specification	Article 2010000598 Dimension picture/Dimension sheet: C14 Output speed [1/min; 1/rpm]: 5.40 Translation/Ratio [i]: 245.65 Color/colour: RAL 7011 Iron grey/Iron grey Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP55 Design/mounting position: V5-00-AB Output torque [Nm]: 31.0 Direction of rotation: right/right [CW] Output shaft transmission/Output shaft [mm; inch]: V20x36 2nd shaft end gear/2.Output shaft [mm; inch]: V16x28 Gearbox bearing: associated bearing/assigned bearings Oil type/Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.22 Shaft material/Shaft material: C45 Transmission sealing/Sealing: shaft seal (WDR) Viton/shaft seal ring Viton Electrical version/Electrical design: CE Number of poles/Poles: 4 Nominal frequency/ Nominal frequency [Hz]: 50 Nominal voltage/Nominal voltage [V]: 220-240/380-420 Circuit/Wiring: S100 (D/Y) Rated power/ Nominal power [kW]: 0.045 Name motor speed/ Motor speed name [1/rpm]: 1320 Current/Nominal current In [A]: 0.33/0.19 cosPHI/cosPHI: 0.78 KK location/Terminal box position: 3C KK version/Terminal box type: plastic/plastic Winding protection/Motor protector: without/without Output shaft Motor/ Output shaft [mm; inch]: V11x24.5 Engine sealing/Sealing motor: Viton/Viton Insulation class/Insulation class: F Operating mode/Duty type: S1 Fan/Fan: plastic/plastic

HIMMEL - Nr. 504616.06 Type C10-G56M4 referenced worm gear motor product produced by high technology.
Nr. 504616.06 Type C10-G56M4 became irreplaceable of foundations. Nr. 504616.06 Type C10-G56M4 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. We present you the most competative price and delivery time on Nr. 504616.06 Type C10-G56M4 referenced product.

Where can I buy Nr. 504616.06 Type C10-G56M4 by HIMMEL in Macedonia?

You can purchase Nr. 504616.06 Type C10-G56M4 by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the Nr. 504616.06 Type C10-G56M4?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Macedonia?

While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access Nr. 504616.06 Type C10-G56M4 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Nr. 504616.06 Type C10-G56M4 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for Nr. 504616.06 Type C10-G56M4?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
