Prices 831.611 Combimac Macedonia

BRAND	Combimac
Product	831.611
Description	motor
Internal code	ONR3406623
Weight	118
Technical specification	Technical details Article nr. 831.611 Type 50 2 U 61 TEFC Description / Specification = shock proof (medium) / Classification NSN = 6105-17-126-4490 Method of cooling (IEC 60034-6) = IC4A1A1 Medium air Execution (IEC 60034-7) IM V1 Supply voltage (IEC 60092) = 450V 3ph 60 Hz Frame size (IEC 60072-1) 160 M Power rating (IEC 60034-1) = 11 kW special Duty cycle (IEC60034-1) = S1 Connection T-Box -Top-SoS Connection / DoR (IEC 60034-8) = Delta Diagram D.317.311/A-045 Method of starting IEC 60034-12 = DOL Number of poles = 4 Rotation CCW-SoS IEC 60034-8 Speed (synchr.) single = 1800 rpm Insulation F Rise 90°C Ingress Protection (IEC 60034-5) = IP55 Ambient Min. -30 °C Max. 55 °C Thermal protection (IEC 60034-11) = Thermistors 1 x 3 +165°C PT100 Heater(s) = - - Encoder - I/O - Cable glands (threaded holes) = Main 2x M40x1,5 Aux. 2x M20x1,5 - Shock Grade / Specification = not applicable Material (frame) = nodular cast iron - EN-GJS-400-15-EN1563 - 0.7040 Balancing planes Balancing (ISO 21940-32) = half key Level MIL-STD-167-1A, type II not applicable Shaft / flange dim. standard = EN 50347 Shaft material - Shaft loads = not applicable Shaft end one Classification = customer specification Paint system = Epoxy Primer, CN3389E Efficiency IE1 Dimensions/Drawing = C.004.473 as built Mass (approx.) 118 kg

Combimac - 831.611 referenced motor product produced by high technology.
831.611 became irreplaceable of foundations. Our company supply 831.611 referenced product fastest and securest on your request. You can find the most competitive prices about endustriel accessories in our company. Make an offer to us for 831.611 please contact us.

Where can I buy 831.611 by Combimac in Macedonia?

You can purchase 831.611 by Combimac from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.

What is the price of the 831.611?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Combimac in Macedonia?

While we are not the official distributor or seller of Combimac in Macedonia, we source our products from reliable channels and offer you original Combimac equipment at competitive prices.

How can I access 831.611 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 831.611 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 831.611?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
