| BRAND | HIMMEL |
| Product | 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH |
| Description | HIMMEL® flat motor |
| Internal code | ONR4895753 |
| Weight | 70 |
| Technical specification | Dimension sheet: 1NJ012645 K model series/design series: K75 Type/type: KG75.01-AM-LP/2 K-size sheet/dimension sheet: 1NJ012645 Color/colour: RAL 6011 Reseda green 2K/Reseda green 2K PUR Design/mounting position: B3 K-mounting sides: one-sided foot machining Protection class: IP54 K-rating plate/name plate: adhesive label 90x60 /adhesive label 90x60 Rating plate logo/name plate logo: SKY Ambient temperature/ Ambient temperature /Ta [°C]: -20/+40 Output variant: flange disc/flange plate W.diameter/shaft diameter [mm]: 38.1 W. length/shaft length [mm]: 116 (center foot hole to start tool/center foot hole to beginning of tool) Shaft thread: 1" - 8 UNC-R.H. K-flange plates Ø/ external diameter flange [mm]: 140 Impexron GmbH offer Gönningerstr. 99 number: 173904 72793 Pfullingen Date: 15/12/2023 page: 2 Item Item No. Quantity VAT Unit Price Total Price Description [%] net [EUR] [EUR] K tool width [mm]: 0 - 5 Storage AS/Bearing-AS (DE): Double bearing Bearing BS/Bearing-BS (NDE): simple bearing K-elect.connection type/elec. connection mode: terminal box/ terminal box KK material/Terminal box material: aluminum/aluminum KK location/Terminal box position: 3B KK screw connection/gland: (1x) -¾ NPT Label/Approval|Identification/Certification: CE & CSA Number of phases: 3~ Code letter: L Number of pins/Poles: 2 Rated power/nominal power [kW]: 11.0 Rated power/ Nominal power [HP]: 14.8 Nominal motor speed/Nominal motor speed [1/min; rpm]: 3510 Rated frequency/ Nominal frequency [Hz]: 60 Rated voltage/nominal voltage [V]: 230/460 Rated current/Nominal current In [A]: 34.4/17.2 CosPhi/CosPHI: 0.88 Circuit/ Wiring: S200 (YY/Y) Operating mode/Duty type: S 6-75% Operating mode/Duty type CSA/UL: int. duty S6 7.5 min on, 2.5 min off Supply type/power supply: FU operation at rated frequency/ inverter duty at rated Frequency Supply type/power supply CSA/UL: inverter duty at rated frequency Drive protection/motor protection (IEC60034-25): to be guaranteed by system managers/to be Guaranteed by System Manager Winding protection/Motor protector: ohne/without Insulation class: F Ventilation type CSA/UL: TEFC Motor circuit diagram/Motor connection diagram: A0200000 Circuit diagram built-in 2/Con. diagram compon. 2: A010414 |
Where can I buy 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH by HIMMEL in Macedonia?
You can purchase 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH by HIMMEL from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in Macedonia?
While we are not the official distributor or seller of HIMMEL in Macedonia, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 2140003222 - KG75.01-AM-LP/2 1"-8UNC-RH?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
