| BRAND | S+S REGELTECHNIK |
| Product | 1101-31D2-0069-810 |
| Description | Duct/ smoke gas temperature measuring transducer |
| Internal code | ONR4621494 |
| Weight | 1.5 |
| Technical specification | RGTM1-I 300MM KV Power consumption < 1.0 VA/ 24 V AC/ DC; < 0.55 VA/ 24 V DC Voltage supply 15...36 V DC depending on working resistance, residual ripple stabilised ± 0.3 V Working resistance máx. 750 Ohm/ 24 V DC Temperature deviation typically ± 0.2 K at +25 °C Sensor Pt1000, DIN EN 60751, class B, glass sensing resistor (Perfect Sensor Protection) Connection type 2- or 3-wire connection Measuring ranges multi-range switching with 8 switchable measuring ranges, see table (other ranges optional) with manual zero point correction (± 10 K) Ambient temperature Measuring transducer –30...+70 °C Process connection by mounting flange, stainless steel V2A (1.4305) (included in the scope of delivery) Protective tube stainless steel, 1.4571, V4A, Ø = 8 mm Electrical connection 0.2 - 1.5 mm², via push-in terminal Connecting head form B, material aluminium, colour white aluminium (similar to RAL 9006), M 20 x 1.5 Output 4...20 mA Permissible air humidity < 95 % r. H., non-precipitating air Protection class III (according to EN 60 730) |
Where can I buy 1101-31D2-0069-810 by S+S REGELTECHNIK in Macedonia?
You can purchase 1101-31D2-0069-810 by S+S REGELTECHNIK from Onrion LLC. We serve customers across Macedonia, offering competitive prices and reliable service.
What is the price of the 1101-31D2-0069-810?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of S+S REGELTECHNIK in Macedonia?
While we are not the official distributor or seller of S+S REGELTECHNIK in Macedonia, we source our products from reliable channels and offer you original S+S REGELTECHNIK equipment at competitive prices.
How can I access 1101-31D2-0069-810 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1101-31D2-0069-810 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1101-31D2-0069-810?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
